| CPU | MediaTek MT6761 Quad-core 2.0GHz,or MT6762 Octa-core 2.0Ghz is
optional |
| Operation System | Android 9.0 without GMS |
| Display & Touch Screnn | 8inch Capacitive Multi-touch IPS HD screen 1280*800pixels,IPS FHD
screen 1920*1200pixels is optional |
| Two Cameras | Front 2.0MP camera, Back 5.0MP Camera,5MP+13MP cameras is optional
for bulk order |
Memory & Storage | 2GBram+32GBRom (default),3GBram+32GB Rom for MT6761 is
optional,4GBram+64GBRom for MT6761, or 4GBRam +64GB Rom or
6GB+128GB for MT6762 is optional for bulk order |
| Network | 4G Networks: Support GSM: B5/B8/B3/B2=850/900/1800/1900Mhz,
3G WCDMA: B1/B5/B8=2100/850/900MHZ;
4G TDD-LTE: B34/B39/B40/B41;4G FDD LTE: B1/B2/B3/B5/B7/B8/B20;
American Version 4G FDD: B4 or B17 is optional For >=1000units
order |
| Wireless Network | Wifi 802.11 a/b/g/n/ac 2.4G+5.0Ghz dual-band wifi and BT4.1 |
| Battery | Built-in 8200mah lithium battery,10000mah is optional for bulk
order |
| I/O Ports | 1*DC port,1*Type-C USB Port,1*RS232 Serial port, 1*Earphone jack, 1*micro Sim card slot, 1*TF card slot, 1* Ethernet RJ45 Port POE (optional) |
| Rugged Durability | Waterproof and dustproof rate:IP65; Ruggedness:comply with 1.0Meter
dropproof |
| Front NFC | NXP PN533,13.56Mhz,support ISO1444A/B,ISO15693,Mifare; is optional |
| 2D Barcode Scanner | GROW GM65 2D barcode or Honeywell N3680 2D barcode is optional |
| Fingerprint scanner | 508dpi,256*288pixels,512-bit,1000 storage,safe rate=grade
5th,FAR<0.001%, normal; FBI certificated or Optical fingerprint (Safran), is optional |
| UHF RFID | 840-920Mhz,normal UHF RFID readable distance is about 1.5 meters or
R2000 readable >=5.0meters,2.4Ghz RFID NRF52832 is optional. |
| Lora Wifi | 433Mhz,is optional |
| Temperature-measurement module | Using infrared temperature sensor and advanced software algorithm,measure the temperature of the
objects, measurement accuracy can be achieved ±0.3℃, is optional |
| Vehicle holder and Charger or Wall bracket |
VESA design,are optional |
| IRIS module: | dual-eyes,5V,recognition time <1s,usage distance 10-20cm,support
ISO8583,ISO/IEC 19794-6,is optional. |
| Face recognition module | is optional |
| Dimension | about 250*166*26mm |
